1/2
Slika je simbolična
Siemens 3SE5 3SE5000-0AA61- vrtljiva ročica z nastavljivo dolžino, Rotary pogon, kovinski vzvod
Vrsta izdelka
dodatno sprožilo
Značilnosti stikal/tipk
mreža iz lukenj
Izvedba
Ročica 19 mm
Motiv za tisk
brez
Aktivacija - vrsta
valj iz legiranega jekla
Podatkovni list izdelka (PDF)
Ean:
Koda proizvajalca:
Št. izdelka:
Število
Skupaj (37,99 € / Kos)
37,99 €
z DDV
Vključena je 14-dnevna politika vračila
Tehnične specifikacije
- Vrsta izdelka
dodatno sprožilo
- Značilnosti stikal/tipk
mreža iz lukenj
- Izvedba
Ročica 19 mm
- Motiv za tisk
brez
- Aktivacija - vrsta
valj iz legiranega jekla
- Vrsta osvetlitve
brez
- Barva
kovinska
- Dolžina
100 mm
- Primerno za (podrobnosti)
vrtljivi pogon 3SE5
- Vsebina
1 kos
- Vrsta
3SE5000-0AA61
- Skladnost z RoHS
Ja
Other
None
None
None
None
Roller cam straight
- UKCA
da
Dokumenti in prenosi
Tehnični podatki
Tehnični podatki 702997 Siemens 3SE5 3SE5000-0AA61- vrtljiva ročica z nastavljivo dolžino, Rotary pogon, kovinski vzvod
Navodila za uporabo in varnost
Navodila za uporabo in varnost 702997 Siemens 3SE5 3SE5000-0AA61- vrtljiva ročica z nastavljivo dolžino, Rotary pogon, kovinski vzvod
Opis
Adjustable-length Twist lever for position switch 3SE51/52 Metal lever 100 mm long Positive fit (grid hole) Stainless steel roller 19 mm actuator for part-turn actuator SIRIUS 3SE5 for position sensing of machine parts and position monitoring of protection equipment.
The modular design of the 3SE5 position switches permits a host of variants with a small number of bearing types. The wide variety of plug-in connectors and rollers meets almost all everyday requirements in industry. LEDs indicate the current state of the device. Thanks to quick-connect technology, the time required for connection can be considerably reduced. Operating points and mounting in accordance with EN 50047 and EN 50041. The devices have worldwide approval (IEC, UL). With the corresponding switch configuration, the highest safety requirements specified by PL e or SIL 3 can be met. The integrated ASIsafe electronics requires a low current input.
Various enclosure sizes, with different contacts, are available in plastic or metal, or compact design. Some versions are optionally available with an LED status display and M12 plug. The 3SF1 series with direct connection to the AS-Interface bus system completes the portfolio.
Depending on the design, actuator heads and plug-in connectors, as well as other mounting/connection accessories, are available.
Safety is a SIRIUS business.
The modular design of the 3SE5 position switches permits a host of variants with a small number of bearing types. The wide variety of plug-in connectors and rollers meets almost all everyday requirements in industry. LEDs indicate the current state of the device. Thanks to quick-connect technology, the time required for connection can be considerably reduced. Operating points and mounting in accordance with EN 50047 and EN 50041. The devices have worldwide approval (IEC, UL). With the corresponding switch configuration, the highest safety requirements specified by PL e or SIL 3 can be met. The integrated ASIsafe electronics requires a low current input.
Various enclosure sizes, with different contacts, are available in plastic or metal, or compact design. Some versions are optionally available with an LED status display and M12 plug. The 3SF1 series with direct connection to the AS-Interface bus system completes the portfolio.
Depending on the design, actuator heads and plug-in connectors, as well as other mounting/connection accessories, are available.
Safety is a SIRIUS business.
Obseg dostave
- Siemens 3SE5 3SE5000-0AA61- vrtljiva ročica z nastavljivo dolžino, Rotary pogon, kovinski vzvod
Namigi
Montaža možna samo z ustreznim vrtljivim pogonom pod kat. št. 70 30 19.
